| Place of Origin: | China |
| Brand Name: | FZ |
| Certification: | CE |
| Model Number: | DNW-33QL |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plastic films or can be customized. |
| Delivery Time: | 30 days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 50 sets per month |
| Type: | Automatic Max. Mesh Width 3000mm Wire Mesh Bending Machine | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
|---|---|---|---|
| Material Of Machine: | Heavy Plates | Wire Diameter Range: | 4-8mm |
| Machinery Test Report: | Provided | Key Selling Points: | Full Automatic |
| Color: | Grey And Yellow | Usage: | Mesh Bending |
| Lead Time: | 50 Days | Welding Method: | Pneumatic |
| Voltage: | 220V/380V/415V/440V | ||
| Highlight: | width 3300mm wire mesh bending machine,pneumatic wire mesh bending machine,programming adjustments wire mesh bending machine |
||
Width 3300mm Pneumatic Bending Machine Programming Adjustments
As the structure of tunnel support system, subway segment is an important part of tunnel structure, and it is the outermost barrier to the tunnel, which bears the function of resisting coating pressure, groundwater pressure and some special loads. affecting the waterproof and durability of the tunnel. The segment is used in the shield construction of the tunnel. After the shield machine is pushed forward, several segments are assembled around the tunnel to form a ring, and then bolted to form the lining of the tunnel to withstand the earth pressure Force.
| Item | Product type | Parameter | Remark |
| 1 | Max. welding capacity | ¢ 6+6mm | |
| 2 | Long wire diameter | ¢3-6mm | |
| 3 | Cross wire diameter | ¢3-6mm | |
| 4 | Long wire feeding method | In pre-cut | |
| 5 | Cross wire feeding method | In pre-cut | |
| 6 | Long wire spacing | ≥50mm | Mechanically adjustments |
| 7 | Cross wire spacing | ≥50mm | Programming adjustments |
| 8 | Length range of wire mesh | ≤3000mm | Adjustable |
| 9 | Width range of wire mesh | ≤1300mm | Adjustable |
| 10 | Number of welding spot | 16PCS | |
| 11 | Working speed max. | 40-60times/min |
1 By means of hydraulic bending, the mesh is placed manually in the fixed position of the Automatic Max. Mesh Width 3300mm Wire Mesh Bending Machine.
2 After starting the switch, the upper beam of Automatic Max. Mesh Width 3300mm Wire Mesh Bending Machine bends the mesh by hydraulic pressure,
3 the die needs to be replaced at different Automatic Max. Mesh Width 3300mm Wire Mesh Bending Machine angles and shapes.
