Place of Origin: | China |
Brand Name: | FZ |
Certification: | CE |
Model Number: | DNW-25Q |
Minimum Order Quantity: | 1 set |
---|---|
Price: | Negotiable |
Packaging Details: | Plastic films or can be customized. |
Delivery Time: | 30 days |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 50 sets per month |
Type: | 2500mm Width 3D Fence Panel Making Wire Mesh Bending Machine | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
---|---|---|---|
Voltage: | 220V/380V/415V/440V | Wire Diameter Range: | 3-6mm |
Machinery Test Report: | Provided | Key Selling Points: | 3D Fence Mesh |
Color: | Customized | Usage: | 3D Fence Mesh |
Lead Time: | 15 Days | Certification: | CE ISO |
Highlight: | 2500mm Width Wire Mesh Bending Machine,220V Wire Mesh Bending Machine,220V 3D Wire Mesh Making Machine |
2500mm Width 3D Fence Panel Making Wire Mesh Bending Machine
The coil dropping material consists of the rear material warehouse , wire guide device , wire holding device and wire dropping device .After the wire is put into the rear material warehouse , the guide wire holding device will grasp the small material warehouse placed in the wire device . There is a detection switch to detect whether the wire exists . When the detection switch detects that there is no wire , the guide wire device starts to work and grab the wire to the position of the wire holding device ; When the automatic operation starts , when the falling wire through the position of the wire template , the cylinder work , the wire to the V groove template , when the wire falls , the wire device two detection switch , to the wire operation signal , the wire device is driven by the servo motor , send the wire of the small material warehouse to the wire device , the stop of the wire detection stop switch .When the template runs to the next V slot , make the next drop .The device consists of the inner and outer plates , which changes the size of the inner and outer plates to accommodate a single wire and not two wires at the same time .adapted it to different wire diameter requirements .
Item | Product type | Parameter | Remark |
1 | Max. welding capacity | ¢ 6+6mm | |
2 | Long wire diameter | ¢3-6mm | |
3 | Cross wire diameter | ¢3-6mm | |
4 | Long wire feeding method | In pre-cut | |
5 | Cross wire feeding method | In pre-cut | |
6 | Long wire spacing | ≥50mm | Mechanically adjustments |
7 | Cross wire spacing | ≥50mm | Programming adjustments |
8 | Length range of wire mesh | ≤3000mm | Adjustable |
9 | Width range of wire mesh | ≤1300mm | Adjustable |
10 | Number of welding spot | 16PCS | |
11 | Working speed max. | 40-60times/min |
Our company can tailor-made various series of mesh welding equipments depending on different fields, including reinforcing mesh welding production line, autoclaved aerated panel mesh welding line, mine supporting mesh welding line, 3D oblique frame welding production line, fence mesh welding production line, shelf mesh welding production line, shelters mesh welding production line, storage cage mesh welding production line, mesh basket welding production line, pet cage mesh welding production line, protective shield mesh welding production line, trolley mesh welding production line, breeding mesh welding production line, high speed wire straightening & cutting machine and etc. Since the products has been launched into the market, we have obtained high praise from numerous customers because of its high automation, high stability, convenient operation and etc.
Contact Person: Bella
Tel: +8613283273008
