Cantilever / Stacking Container Wire Mesh Welding Machine 220v

Cantilever Mesh Stacking Wire Mesh Container Welding Machine

Notes during operation

Watch the touch screen to see if it shows normal. When the alarm occurs, first see the contents of the alarm, and then follow the instructions to check the relevant parts and resolve.

Pay attention to whether the wire throwing part can work properly, if not normal must adjust the equipment in time, otherwise it will cause the cross wire throwing is not in place, the mesh lack of silk phenomenon.

Pay attention to the sound of welding, normally there is a slight sound. When the welding sound is large and the spark spatter is serious, it may be caused by the following reasons:

①　There is rust or oil stain on the surface of the wire.

②　The welding pressure is too small and the transformer gear is too high.

③　upper and lower contacts have oil stain.

Pay attention to check the solder joint, the strong solder joint diameter wire and weft wire down pressure is about 15%, and the long wire and cross wire contact with the upper and lower electrodes should not deform.

This device is the core part of Cantilever Mesh Stacking Wire Mesh Container Welding Machine. It is mainly to weld the meshes at a high speed by cooperating closely with others device.

The welding electrodes head of Cantilever Mesh Stacking Wire Mesh Container Welding Machine use high-quality materials, which make them more wearable and with better conductive, and also have a long life, reduce production costs.

The improvement of design of welding transformers of Fence Mesh Welding Machine meets the demand to weld continuously wires of 6+6mm at a high speed at the moment when saving energy.

Fence Mesh Welding Machine electrodes adopt circulating water cooling, which extends their service lives, and ensures the long-term operation of the equipment.
