| Place of Origin: | China |
| Brand Name: | FZ |
| Certification: | CE. ISO |
| Model Number: | DNW-15Q |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plastic films or can be customized. |
| Delivery Time: | 40 days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 20 sets per month |
| Material Of Machine: | Heavy Plates And Section Bars | Wire Diameter Range: | 3-6mm |
|---|---|---|---|
| Machinery Test Report: | Provided | Key Selling Points: | Full Automatic |
| Color: | Grey& Yellow Or Can Be Customized | Usage: | SS Wire |
| Lead Time: | 30 Days | Welding Method: | Pneumatic |
| Automation Degree: | Full Automatic | Certification: | CE ISO |
| Highlight: | Spacing 50mm Wire Mesh Spot Welding Machine,Pneumatic Bending Wire Mesh Spot Welding Machine,50mm Pneumatic Bending Machine |
||
SS Cable Tray With Difference Type Wire Mesh Bending Machine
the difference type with both side long wire spacing distance 25mm and the middle 50mm. the others customers may need 30mm wire mesh in different industry. the width can change according to your need.
| Item | Product type | Parameter | Remark |
| 1 | Max. welding capacity | ¢ 6+6mm | |
| 2 | Long wire diameter | ¢3-6mm | |
| 3 | Cross wire diameter | ¢3-6mm | |
| 4 | Long wire feeding method | In pre-cut | |
| 5 | Cross wire feeding method | In pre-cut | |
| 6 | Long wire spacing | ≥50mm | Mechanically adjustments |
| 7 | Cross wire spacing | ≥50mm | Programming adjustments |
| 8 | Length range of wire mesh | ≤3000mm | Adjustable |
| 9 | Width range of wire mesh | ≤1300mm | Adjustable |
| 10 | Number of welding spot | 32PCS | |
| 11 | Working speed max. | 40-60times/min |
after the welding , the mesh will be the second working procress, bending the both side .
then can make the final products
