| Place of Origin: | China |
| Brand Name: | FZ |
| Certification: | CE ISO |
| Model Number: | DNW-25Q |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plastic films or can be customized. |
| Delivery Time: | 30 days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 50 sets per month |
| Usage: | Roll Mesh | Lead Time: | 25 Days |
|---|---|---|---|
| Welding Method: | Pneumatic | Automation Degree: | Full Automatic |
| Producton Capacity: | 50 Sets/Month | Voltage: | 220V/380V/415V/440V |
| Control System: | PLC | Cooling Method: | Water Cooling |
| Warranty: | 1 Year | ||
| Highlight: | 220V Roll Mesh Welding Machine,PLC Roll Mesh Welding Machine,Ribbed Steel Rolling Welding Machine |
||
Cold Rolled Ribbed Steel Wire Roll Mesh Welding Machine
Do not use in the following places: places with corrosive liquids, dust, smoke and dangerous goods and combustible gases; places exposed to high temperature, condensation, wind and rain; places with vibration and shock. Misoperation may also cause damage to the machine.
When hoisting, must choose the appropriate hoisting tools, otherwise may cause personnel injury and machine damage.
When bolt connection, the connection must be fastened to ensure that the installation must be in place, otherwise it may cause human injury.
| Item | Product type | Parameter | Remark |
| 1 | Max. welding capacity | ¢ 6+6mm | |
| 2 | Long wire diameter | ¢3-6mm | |
| 3 | Cross wire diameter | ¢3-6mm | |
| 4 | Long wire feeding method | In coil | |
| 5 | Cross wire feeding method | In pre-cut | |
| 6 | Long wire spacing | ≥50mm | Mechanically adjustments |
| 7 | Cross wire spacing | ≥50mm | Programming adjustments |
| 8 | Length range of wire mesh | ≤60000mm | Adjustable |
| 9 | Width range of wire mesh | ≤2500mm | Adjustable |
| 10 | Number of welding spot | 16PCS | |
| 11 | Working speed max. | 40-60times/min |
Welding forming mesh, the motor of Construction Full Automatically Roll Mesh Welding Machine gives the roll power, the mesh is rolled, the whole mesh is finished, one end of the Construction Full Automatically Roll Mesh Welding Machine is opened, and the other end is automatically rolled out by Construction Full Automatically Roll Mesh Welding Machine.
